Sanyo NCR18650GA 3450mAh 10A Battery - Button Top
Key Features
- High-capacity 3450mAh lithium-ion cell for extended runtime
- 10A maximum continuous discharge for demanding applications
- Button top terminal for compatibility with select devices
- High energy density: 693 Wh/L volumetric, 224 Wh/kg gravimetric
- Wide operating temperature range from -20°C to +60°C
Overview
The Panasonic NCR18650GA is a premium high-capacity lithium-ion battery engineered for applications that require long runtime and stable power delivery. With a typical capacity of 3450mAh and a 10A continuous discharge rating, this cell strikes an excellent balance between energy density and output capability. This version features a button top terminal and is unprotected, making it suitable for devices or battery packs with built-in protection circuitry.
Applications / Uses
- Portable power tools with internal protection
- E-bike battery packs
- High-capacity battery assemblies
- Energy storage systems
- Professional-grade electronics
SPECIFICATIONS
| Manufacturer | Panasonic |
| Model | NCR18650GA |
| Size | 18650 |
| Positive Terminal | Button Top |
| Nominal Capacity | 3450mAh (Typical) |
| Continuous Discharge Rating | 10A Maximum Continuous |
| Nominal Voltage | 3.6V |
| Maximum Voltage | 4.2V |
| Discharge Cut-off Voltage | 2.5V |
| Protected | No, Unprotected |
| Rechargeable | Yes |
| Approx. Dimensions | 18.5mm × 66.8mm |
| Approx. Weight | 48.2g |
| Country of Origin | China or Japan |
| Data Specification Sheet | Panasonic NCR18650GA Datasheet |
