Panasonic NCR18650GA 3450mAh Battery - Protected Button Top

Key Features

• High-capacity 3450mAh cell for extended runtime
• Up to 10A continuous discharge capability
• Protected button-top design with integrated PCB
• High energy density for compact power solutions
• Stable voltage performance under sustained load

Note: This is a button top protected 18650 battery which is longer than a standard flat top unprotected 18650 battery.

Overview

The Panasonic NCR18650GA is a high-energy 18650 lithium-ion battery engineered for applications that require long runtime and dependable output. With a typical capacity of 3450mAh and support for continuous discharge up to 10A, this cell delivers efficient, stable power while maintaining excellent energy density and operational reliability.

Applications / Uses

• Portable power equipment
• Battery pack assemblies
• Energy storage modules
• High-efficiency electronic systems
• Professional and industrial devices

SPECIFICATIONS

Manufacturer	Panasonic
Model	NCR18650GA
Size	18650
Positive Terminal	Button Top
Nominal Capacity	3450mAh (Typical)
Continuous Discharge Rating	10A (5A PCB Limit)
Nominal Voltage	3.6V
Maximum Voltage	4.2V
Discharge Cut-Off Voltage	2.5V
Protected	Yes (PCB)
Rechargeable	Yes
Approx. Dimensions	18.5mm × 69.5mm
Approx. Weight	49.4g
Data Specification Sheet	Panasonic NCR18650GA Datasheet
